Composite Balustrade Gate
Composite Balustrade Gate
SKU: NT-CBS-GAT-GREYNot sure which colour? Order free samples · Questions? Speak to an expert
Product benefits
Why choose Grainex® composite
Up to 25-Year Warranty
The most comprehensive warranty available on UK composite products. Residential and commercial cover included.
Zero Maintenance
Never sand, paint, stain or treat. A simple wash with soapy water is all that's ever needed.
Anti-Slip Both Sides
Embossed grip texture on both board faces provides safe footing in wet conditions year-round.
Fade & Stain Resistant
UV-stabilised composite won't fade, splinter or rot. Resists mould, algae, oil and wine stains.
Weatherproof
Handles British frost, rain and UV without warping, cracking or delaminating.
Eco-Responsible
Made from recycled wood fibres and reclaimed plastics. FSC-certified. A sustainable timber alternative.
About this product
Composite Balustrade Gate provides a stylish, matching gate for use within your NeoTimber® composite balustrade system. This 1068mm x 873mm gate is constructed from the same premium composite material as the balustrade posts and railings, offering a seamless, coordinated look for decks, terraces and garden boundaries. Available in all eight NeoTimber® colours.
Exclusively handpicked excellence, manufactured and distributed by NeoTimber®
Technical Specifications
| Product name | Composite Balustrade Gate |
| SKU | NT-CBS-GAT-GREY |
| Material | Co-extruded composite (WPC) — recycled wood fibre & HDPE |
| Board length | 3.6m |
| Board width | 145mm |
| Board thickness | 25mm |
| Weight per board | approx. 6.2kg |
| Coverage per board | approx. 0.52m² |
| Core construction | Hollow twin-wall |
| Surface finish | Co-extruded cap both sides, anti-slip emboss |
| Minimum joist spacing | 400mm perpendicular / 300mm diagonal |
| Fire classification | Euroclass E |
| Residential warranty | Up to 25 years |
| Commercial warranty | 10 years |
Compare the Full Range
Find the right fence panel for your boundary.
| Feature | Deluxe Composite | Slatted Composite |
|---|---|---|
| Style | Solid woodgrain | Modern horizontal slatted |
| Slat / board dimensions | Board 145×24mm | Slat 176×24×1726mm |
| Panel coverage | 1.83m wide × 1.8m high | 1.83m wide × 1.8m high |
| Post options | Aluminium (hard) or composite (soft) | Aluminium (hard) or composite (soft) |
| Privacy | Full | High |
| Wind resistance | Excellent | Good |
| Colours available | 8 | 8 |
| Best for | Privacy and screening | Contemporary garden design |
Installation Guide
A composite balustrade can be installed in a weekend. Always check UK Building Regulations Part K (1100mm minimum height, 100mm maximum gap).
Plan post positions
Posts must be no more than 1.5m apart, with a post at every corner, end and either side of any opening. Mark the deck or substrate clearly.
Secure the posts
Use heavy-duty post bolts through pre-drilled base plates into the deck joist or concrete pad below. Posts must be perfectly plumb in both axes — use a spirit level on adjacent faces.
Cut railings to length
Measure post-to-post and cut top and bottom rails. Allow a 3mm gap at each end for expansion.
Fit the spindles
Slot spindles into the bottom rail's pre-drilled holes (19 spindles per 1816mm panel). Maximum 100mm centre-to-centre to comply with Building Regs.
Fix the top rail
Lower the top rail onto the spindles, ensuring all spindles seat fully. Screw into each post through the rail's hidden brackets.
Cap and finish
Fit decorative post caps. Check the entire run for level and rigidity. Apply a final wash with soapy water.
